Application:
- ISUZU FVZ 20000L stainless steel water delivery truck for drinking water also called Potable Water Service Truck, Potable water bowser, Stainless steel drinking water truck are used to deliver potable drinking water.
- Our tanks transport water that is dispensed through a pumping system either through a hose reel for delivery or through a series of spray heads and nozzles to spray the water in different directions.
- The water tanker volume can be from 2,000liters to 35,000liters
Advantage:
- 6×4 ISUZU FVZ chassis, perfect performance
- 100% custom-made
- ISUZU engine, super powerful; reliable performance, no overhaul within 500,000 km.
- stainless steel Water pump super powerful, efficient pump in and out
- Stainless steel pipes, longer service life
- Easy operation & Easy maintenance
- 2,000L to 35,000L available
- Short delivery time 7~30 days
- 15 years spare parts & Technical support
Specification:
Item | Unit | Description | ||||||||
Model | ISUZU FVZ 20000L stainless steel water delivery truck for sale | |||||||||
Dimension | mm | 10500x2500x3400 | ||||||||
Sample Tank Dimension | mm | 7500 length * 2300 width * 1400 height , ellipse | ||||||||
Litter | 20000 | |||||||||
material | Inside tank 304-2B material, 4 mm thick | |||||||||
Curb Weight | kg | 10765 | ||||||||
G.V.W | kg | 26000 | ||||||||
Wheel Base | mm | 4350+1300 | ||||||||
F/R track base | mm | 1876/1820 | ||||||||
F/R Axle-Load | Kg | 7000 / 10000 /10000 | ||||||||
Type | Steel Spring Type | |||||||||
Approach/Departure angle | . | 23 / 13 | ||||||||
Traction system | Type | 6*4 | ||||||||
Max speed | Km/h | 90 | ||||||||
Tire Specification/Number | Model | 11.00R20 , 10 Unit +1 Spare Unit | ||||||||
Engine model | Model | 6UZ1 | ||||||||
Emission/Kw | 9800 cc / 257 Kw~2200 rpm | |||||||||
Horse Power | 350 | |||||||||
Max Power | 1090 N.m – 1200 r/min | |||||||||
Type | Diesel, 6 cylinders, Turbocharged , Inter-Cooling | |||||||||
manufacturer | ISUZU FVZ | |||||||||
Standard | Euro II | |||||||||
Gear box | Type | 9 F & 1R , Manual , RT-11509C | ||||||||
Brand | Fast Brand | |||||||||
Fuel Tank | Liter | 350 | ||||||||
Electric system | V | 24 | ||||||||
Cab | Person | 3 | ||||||||
Type | Reversible, Manual | |||||||||
Steering | Powering, LHD | |||||||||
Installing | Mp3, Radio | |||||||||
Air Conditioner | Hot Wind / Cold Wind | |||||||||
Equipment | Installed | 1.) installing Stainless steel water pump 2.) Option ~ Installing Dom alarm light on the cab |
Standard configuration:
Optional configuration:
Technical training support:
Truck Tools:
- Free parts for 12 months.
- Supply of original parts.
- DHL serves 7 days worldwide.
Factory Advantage:
- 16 years of design and export experience.
- 100% customized trucks.
- Quick delivery guarantee.
Export Documents:
- Serving more than 80 countries and regions.
- Professional guidance on import documents.
- CO, FORM E, FORM P, pre-implantation inspection
Truck shipping:
- Maximize your shipping costs.
- Professional guidance on import documents.
- Safe, fast and timely
Bulk order case:
- Fast shipping to all parts of the world.
- The truck color and logo can be customized.
