JMC mini dump truck price Cambodia

[Technical parameters of the vehicle]

product name

JX3041ZXETSA26 JMC mini dump truck

Total mass (kg)

4100

Tank volume (m3)

3

Rated mass (kg)

1295

Dimensions (mm)

4845X1880X2075

Curb weight (kg)

2480

Cargo compartment size (mm)

2190X1800X400

The number of passengers in the cab (person)

2+3

Maximum load of saddle (kg)

Approach angle/departure angle (°)

21/20

Front suspension/rear suspension (mm)

1075/1310

Axle load (kg)

1435/2665

Maximum speed (km/h)

100

Remark:

Remarks: 1. The dumping type is rear dumping. 2. ABS system model: APG3550500A, ABS system manufacturer: Zhejiang

Jiangyatai Electromechanical Co., Ltd.; 3. Side protection device material: Q235, connection method: bolt connection; rear lower protection device material

: Q235, connection method: bolt connection, section size: 100mm×45mm, ground clearance: 470mm; 4. Launch

The maximum net power of the machine: 83kw; 5. Only the first-level reflective logo is used to paste the tail; the black film on the door frame is optional. 6. Engine model

Corresponding fuel consumption declared value: JX4D30B6H/8.4L/100km; front face, front lamps, and exterior mirrors are optional with the chassis

. Optional tail lamps are installed with the chassis. Extend the front appearance of the condenser in the lower part of the cab. Optional fuel tank appearance, optional aluminum alloy wheel material, optional without

Spare tire.

【Chassis technical parameters】

Chassis model

JX1041TSA26

Chassis name

Truck chassis

Trade name

JMC

manufacturer

Jiangling Motors Co., Ltd.

Number of axes

2

Number of tires

6

Wheelbase (mm)

2460

Tire specifications

7.00R16LT 8PR

Number of leaf spring

7/4+6,7/3+2,7/3+3,7/3+4,7/4+2,7/4+3,7/4+4

Front track (mm)

1385

Fuel type

diesel fuel

Rear track (mm)

1425

Emission standard

GB3847-2005, GB17691-2018 National Ⅵ

engine model

Engine manufacturer

engine capacity

Engine power

JX4D30B6H

Jiangling Motors Co., Ltd.

2892

85
